Heavy-Duty Cantilever RackingHeavy-Duty Cantilever Racks are completely adjustable for application specific design flexibility. Long, unwelded stock is handled quickly and efficiently by forklift; instant accessibility to one piece or a full load. Arms are adjustable up and down the length of the upright. Pre-drilled holes on the uprights are spaced every 3-1/2" for bolt-on arm placement (hardware included). All arms feature lips to prevent product from falling off. Standard arms have a 3-1/8" lip. Heavy-duty and extra heavy-duty have a 3-1/4" lip. Uprights and arms are sold each, not in pairs. Custom rack systems can be designed for your special application. *Capacity listed is per upright.
Check Out Vestil's Other Cantilever Racking:
 Standard-Duty Cantilever Racking |
 Medium-Duty Cantilever Racking |
 Cantilever Rack Kits |
Medium-Duty Cantilever Racking
Cantilever Rack Kits
Standard-Duty Cantilever RackingAdditional Models In This Family
HU-C-14-36
HU-C-12-18
HB-C-8-4
HB-C-14-5
HU-C-12-36
HB-C-14-8
HDSA-C-48M
HB-C-14-8
HB-C-8-7
HB-C-8-4
HU-C-8-48
HB-C-14-3
HDU-C-12-24
HU-C-12-24
HSA-C-36
All measurements are approximate. Slight variations, tolerances or changes may occur at any time. Weights shown are approximate shipping weights.
The Search Box below is within the Model Chart for this Product Family (on this current page). Not an entire site search.
| Model # | Description | Attributes | Net Wt. (lbs) |
||||
|---|---|---|---|---|---|---|---|
| HSA-C-24 |  | 1 Year Limited Warranty | Steel Heavy Duty Cantilever Straight Arm 24 In. 2,000 Lb. Capacity Orange | Uniform Capacity Per Arm (lb.): 2,000 Component: Straight Arm | 21 | ||
| HB-C-14-3 | | 1 Year Limited Warranty | Steel Heavy Duty Cantilever Brace Set 144 In. x 36 In. Blue | Component: Brace Set Fits Upright (in.): 144 and 168 | 44 | ||
| HB-C-14-4 |  | 1 Year Limited Warranty | Steel Heavy Duty Cantilever Brace Set 144 In. x 48 In. Blue | Component: Brace Set Fits Upright (in.): 144 and 168 | 54 | ||
| HB-C-14-5 | | 1 Year Limited Warranty | Steel Heavy Duty Cantilever Brace Set 144 In. x 60 In. Blue | Component: Brace Set Fits Upright (in.): 144 and 168 | 56 | ||
| HB-C-14-6 |  | 1 Year Limited Warranty | Steel Heavy Duty Cantilever Brace Set 144 In. x 72 In. Blue | Component: Brace Set Fits Upright (in.): 144 and 168 | 66 | ||
| HB-C-14-7 |  | 1 Year Limited Warranty | Steel Heavy Duty Cantilever Brace Set 144 In. x 84 In. Blue | Component: Brace Set Fits Upright (in.): 144 and 168 | 78 | ||
| HB-C-14-8 | | 1 Year Limited Warranty | Steel Heavy Duty Cantilever Brace Set 144 In. x 96 In. Blue | Component: Brace Set Fits Upright (in.): 144 and 168 | 123 | ||
| HB-C-8-3 |  | 1 Year Limited Warranty | Steel Heavy Duty Cantilever Brace Set 96 In. x 36 In. Blue | Component: Brace Set Fits Upright (in.): 96 and 120 | 28 | ||
| HB-C-8-4 | | 1 Year Limited Warranty | Steel Heavy Duty Cantilever Brace Set 96 In. x 48 In. Blue | Component: Brace Set Fits Upright (in.): 96 and 120 | 31 | ||
| HB-C-8-5 |  | 1 Year Limited Warranty | Steel Heavy Duty Cantilever Brace Set 96 In. x 60 In. Blue | Component: Brace Set Fits Upright (in.): 96 and 120 | 38 | ||
| HB-C-8-6 |  | 1 Year Limited Warranty | Steel Heavy Duty Cantilever Brace Set 96 In. x 72 In. Blue | Component: Brace Set Fits Upright (in.): 96 and 120 | 43 | ||
| HB-C-8-7 | | 1 Year Limited Warranty | Steel Heavy Duty Cantilever Brace Set 96 In. x 84 In. Blue | Component: Brace Set Fits Upright (in.): 96 and 120 | 98 | ||
| HB-C-8-8 |  | 1 Year Limited Warranty | Steel Heavy Duty Cantilever Brace Set 96 In. x 96 In. Blue | Component: Brace Set Fits Upright (in.): 96 and 120 | 107 | ||
| HDSA-C-36 |  | 1 Year Limited Warranty | Steel Heavy-Duty Cantilever Straight Arm 36 In. Length 2,175 Lb. Capacity Orange | Uniform Capacity Per Arm (lb.): 2,175 Component: Heavy-Duty Arm | 26 | ||
| HDSA-C-42 |  | 1 Year Limited Warranty | Steel Heavy-Duty Cantilever Straight Arm 42 In. Length 1,865 Lb. Capacity Orange | Uniform Capacity Per Arm (lb.): 1,865 Component: Heavy-Duty Arm | 29 | ||
| HDSA-C-48 |  | 1 Year Limited Warranty | Steel Heavy-Duty Cantilever Straight Arm 48 In. Length 1,630 Lb. Capacity Orange | Uniform Capacity Per Arm (lb.): 1,630 Component: Heavy-Duty Arm | 31 | ||
| HDSA-C-48M |  | 1 Year Limited Warranty | Steel Heavy-Duty Cantilever Straight Arm 48 In. Length 2,000 Lb. Capacity Orange | Uniform Capacity Per Arm (lb.): 2,000 Component: Heavy-Duty Arm | 33 | ||
| HDU-C-10-18 |  | 1 Year Limited Warranty | Steel Heavy Duty Double Cantilever Uprights 10 Ft. 49,200 Lb. Capacity Blue | Uniform Capacity per Upright (lb.): 49,200 Component: Double-Sided Upright | 336 | ||
| HDU-C-10-24 |  | 1 Year Limited Warranty | Steel Heavy Duty Double Cantilever Uprights 10 Ft. 42,600 Lb. Capacity Blue | Uniform Capacity per Upright (lb.): 42,600 Component: Double-Sided Upright | 355 | ||
| HDU-C-10-36 |  | 1 Year Limited Warranty | Steel Heavy Duty Double Cantilever Uprights 10 Ft. 36,400 Lb. Capacity Blue | Uniform Capacity per Upright (lb.): 36,400 or 31,600 Component: Double-Sided Upright | 391 | ||
| HDU-C-10-48 |  | 1 Year Limited Warranty | Steel Heavy Duty Double Sided Cantilever Uprights for 42 In. and 48 In. Arms 10 Ft. 28,200 Lb. Capacity Blue | Uniform Capacity per Upright (lb.): 28,200 or 25,200 Component: Double-Sided Upright | 427 | ||
| HDU-C-12-18 |  | 1 Year Limited Warranty | Steel Heavy Duty Double Sided Cantilever Uprights for 18 In. Arms 12 Ft. 48,800 Lb. Capacity Blue | Uniform Capacity per Upright (lb.): 48,800 Component: Double-Sided Upright | 374 | ||
| HDU-C-12-24 | | 1 Year Limited Warranty | Steel Heavy Duty Double Sided Cantilever Uprights for 24 In. Arms 12 Ft. 41,800 Lb. Capacity Blue | Uniform Capacity per Upright (lb.): 41,800 Component: Double-Sided Upright | 393 | ||
| HDU-C-12-36 |  | 1 Year Limited Warranty | Steel Heavy Duty Double Sided Cantilever Uprights for 30 and 36 In. Arms 12 Ft. 35,600 Lb. Capacity Blue | Uniform Capacity per Upright (lb.): 35,600 or 31,200 Component: Double-Sided Upright | 429 | ||
| HDU-C-12-48 |  | 1 Year Limited Warranty | Steel Heavy Duty Double Sided Cantilever Uprights for 42 and 48 In. Arms 12 Ft. 27,800 Lb. Capacity Blue | Uniform Capacity per Upright (lb.): 27,800 or 25,000 Component: Double-Sided Upright | 465 | ||
| HDU-C-14-18 |  | 1 Year Limited Warranty | Steel Heavy Duty Double Sided Cantilever Uprights for 18 In. Arms 14 Ft. 46,800 Lb. Capacity Blue | Uniform Capacity per Upright (lb.): 46,800 Component: Double-Sided Upright | 413 | ||
| HDU-C-14-24 |  | 1 Year Limited Warranty | Steel Heavy Duty Double Sided Cantilever Uprights for 24 In. Arms 14 Ft. 40,400 Lb. Capacity Blue | Uniform Capacity per Upright (lb.): 40,400 Component: Double-Sided Upright | 432 | ||
| HDU-C-14-36 |  | 1 Year Limited Warranty | Steel Heavy Duty Double Sided Cantilever Uprights for 30 In. and 36 In. Arms 14 Ft. 35,200 Lb. Capacity Blue | Uniform Capacity per Upright (lb.): 35,200 or 30,800 Component: Double-Sided Upright | 467 | ||
| HDU-C-14-48 |  | 1 Year Limited Warranty | Steel Heavy Duty Double Sided Cantilever Uprights for 42 In. and 48 In. Arms 14 Ft. 27,400 Lb. Capacity Blue | Uniform Capacity per Upright (lb.): 27,400 or 24,800 Component: Double-Sided Upright | 507 | ||
| HDU-C-8-18 |  | 1 Year Limited Warranty | Steel Heavy Duty Double Sided Cantilever Uprights for 18 In. Arms 8 Ft. 49,900 Lb. Capacity Blue | Uniform Capacity per Upright (lb.): 49,400 Component: Double-Sided Upright | 288 | ||
| HDU-C-8-24 |  | 1 Year Limited Warranty | Steel Heavy Duty Double Sided Cantilever Uprights for 18 In. Arms 8 Ft. 43,000 Lb. Capacity Blue | Uniform Capacity per Upright (lb.): 43,000 Component: Double-Sided Upright | 307 | ||
| HDU-C-8-36 |  | 1 Year Limited Warranty | Steel Heavy Duty Double Sided Cantilever Uprights for 30 In. and 36 In. Arms 8 Ft. 36,600 Lb. Capacity Blue | Uniform Capacity per Upright (lb.): 36,600 or 32,000 Component: Double-Sided Upright | 342 | ||
| HDU-C-8-48 |  | 1 Year Limited Warranty | Steel Heavy Duty Double Sided Cantilever Uprights for 42 In. and 48 In. Arms 8 Ft. 27,400 Lb. Capacity Blue | Uniform Capacity per Upright (lb.): 28,400 or 25,600 Component: Double-Sided Upright | 378 | ||
| HIA-C-18 |  | 1 Year Limited Warranty | Steel Heavy Duty Cantilever Incline Arm 18 In. Length 2,500 Lb. Capacity Orange | Uniform Capacity Per Arm (lb.): 2,500 Component: Incline Arm | 16 | ||
| HIA-C-24 |  | 1 Year Limited Warranty | Steel Heavy Duty Cantilever Incline Arm 24 In. Length 2,500 Lb. Capacity Orange | Uniform Capacity Per Arm (lb.): 2,000 Component: Incline Arm | 21 | ||
| HIA-C-30 |  | 1 Year Limited Warranty | Steel Heavy Duty Cantilever Incline Arm 30 In. Length 1,500 Lb. Capacity Orange | Uniform Capacity Per Arm (lb.): 1,500 Component: Incline Arm | 22 | ||
| HIA-C-36 |  | 1 Year Limited Warranty | Steel Heavy Duty Cantilever Incline Arm 36 In. Length 1,200 Lb. Capacity Orange | Uniform Capacity Per Arm (lb.): 1,200 Component: Incline Arm | 26 | ||
| HIA-C-42 |  | 1 Year Limited Warranty | Steel Heavy Duty Cantilever Incline Arm 42 In. Length 1,100 Lb. Capacity Orange | Uniform Capacity Per Arm (lb.): 1,100 Component: Incline Arm | 29 | ||
| HIA-C-48 |  | 1 Year Limited Warranty | Steel Heavy Duty Cantilever Incline Arm 48 In. Length 1,000 Lb. Capacity Orange | Uniform Capacity Per Arm (lb.): 1,000 Component: Incline Arm | 32 | ||
| HSA-C-18 |  | 1 Year Limited Warranty | Steel Heavy Duty Cantilever Straight Arm 18 In. 2,500 Lb. Capacity Orange | Uniform Capacity Per Arm (lb.): 2,500 Component: Straight Arm | 16 | ||
| HSA-C-30 |  | 1 Year Limited Warranty | Steel Heavy Duty Cantilever Straight Arm 30 In. 1,500 Lb. Capacity Orange | Uniform Capacity Per Arm (lb.): 1,500 Component: Straight Arm | 22 | ||
| HSA-C-36 | | 1 Year Limited Warranty | Steel Heavy Duty Cantilever Straight Arm 36 In. 1,200 Lb. Capacity Orange | Uniform Capacity Per Arm (lb.): 1,200 Component: Straight Arm | 26 | ||
| HSA-C-42 |  | 1 Year Limited Warranty | Steel Heavy Duty Cantilever Straight Arm 42 In. 1,100 Lb. Capacity Orange | Uniform Capacity Per Arm (lb.): 1,100 Component: Straight Arm | 29 | ||
| HSA-C-48 |  | 1 Year Limited Warranty | Steel Heavy Duty Cantilever Straight Arm 48 In. 1,000 Lb. Capacity Orange | Uniform Capacity Per Arm (lb.): 1,000 Component: Straight Arm | 32 | ||
| HU-C-10-18 |  | 1 Year Limited Warranty | Steel Single Sided Cantilever Upright with 18 In. Arms 10 Ft. 24,700 Lb. Capacity Blue | Uniform Upright Capacity (lb.): 24,700 Component: Single-Sided Upright | 313 | ||
| HU-C-10-24 |  | 1 Year Limited Warranty | Steel Single Sided Cantilever Upright with 24 In. Arms 10 Ft. 21,500 Lb. Capacity Blue | Uniform Upright Capacity (lb.): 21,500 Base Length (in.): 36-1/2 | 323 | ||
| HU-C-10-36 |  | 1 Year Limited Warranty | Steel Single Sided Cantilever Upright with 30 In. and 36 In. Arms 10 Ft. 18,300 Lb. Capacity Blue | Uniform Upright Capacity 30"/36" Arm (lb.): 18,300 or 16,000 Base Length (in.): 48-1/2 | 340 | ||
| HU-C-10-48 |  | 1 Year Limited Warranty | Steel Single Sided Cantilever Upright with 42 In. and 48 In. Arms 10 Ft. 14,200 Lb. Capacity Blue | Uniform Upright Capacity 42"/48" Arm(lb.): 14,200 or 12,800 Base Length (in.): 60-1/2 | 357 | ||
| HU-C-12-18 | | 1 Year Limited Warranty | Steel Single Sided Cantilever Upright with 18 In. Arms 12 Ft. 24,400 Lb. Capacity Blue | Uniform Upright Capacity (lb.): 24,400 Component: Single-Sided Upright | 351 | ||
| HU-C-12-24 | | 1 Year Limited Warranty | Steel Single Sided Cantilever Upright with 24 In. Arms 12 Ft. 20,900 Lb. Capacity Blue | Uniform Upright Capacity (lb.): 20,900 Base Length (in.): 36-1/2 | 362 | ||
| HU-C-12-36 | | 1 Year Limited Warranty | Steel Single Sided Cantilever Upright with 30 In. and 36 In. Arms 12 Ft. 17,800 Lb. Capacity Blue | Uniform Upright Capacity 30"/36" Arm (lb.): 17,800 or 15,600 Base Length (in.): 48-1/2 | 378 | ||
| HU-C-12-48 |  | 1 Year Limited Warranty | Steel Single Sided Cantilever Upright with 42 In. and 48 In. Arms 12 Ft. 13,900 Lb. Capacity Blue | Uniform Upright Capacity 42"/48" Arm(lb.): 13,900 or 12,500 Base Length (in.): 60-1/2 | 396 | ||
| HU-C-14-18 |  | 1 Year Limited Warranty | Single Sided Cantilever Upright with 18 In. Arms 14 Ft. 23,400 Lb. Capacity Blue | Uniform Upright Capacity (lb.): 23,400 Component: Single-Sided Upright | 390 | ||
| HU-C-14-24 |  | 1 Year Limited Warranty | Single Sided Cantilever Upright with 24 In. Arms 14 Ft. 20,200 Lb. Capacity Blue | Uniform Upright Capacity (lb.): 20,200 Component: Single-Sided Upright | 401 | ||
| HU-C-14-36 | | 1 Year Limited Warranty | Single Sided Cantilever Upright with 30 In. and 36 In. Arms 14 Ft. 17,600 Lb. Capacity Blue | Uniform Upright Capacity 30"/36" Arm (lb.): 17,600 or 15,400 Component: Single-Sided Upright | 417 | ||
| HU-C-14-48 |  | 1 Year Limited Warranty | Single Sided Cantilever Upright with 42 In. and 48 In. Arms 14 Ft. 13,700 Lb. Capacity Blue | Uniform Upright Capacity 42"/48" Arm(lb.): 13,700 or 12,400 Component: Single-Sided Upright | 435 | ||
| HU-C-8-18 |  | 1 Year Limited Warranty | Steel Heavy Duty Single Sided Cantilever Upright 18 In. Arms 8 Ft. 24,700 Lb. Capacity Blue | Uniform Upright Capacity (lb.): 24,700 Component: Single-Sided Upright | 265 | ||
| HU-C-8-24 |  | 1 Year Limited Warranty | Steel Heavy Duty Single Sided Cantilever Upright 24 In. Arms 8 Ft. 21,500 Lb. Capacity Blue | Uniform Upright Capacity (lb.): 21,500 Component: Single-Sided Upright | 275 | ||
| HU-C-8-36 |  | 1 Year Limited Warranty | Steel Heavy Duty Single Sided Cantilever Upright 30 In. and 36 In. Arms 8 Ft. 18,300-16,000 Lb. Capacity Blue | Uniform Upright Capacity 30"/36" Arm (lb.): 18,300 or 16,000 Component: Single-Sided Upright | 292 | ||
| HU-C-8-48 | | 1 Year Limited Warranty | Steel Heavy Duty Single Sided Cantilever Upright with 42 In. and 48 In. Arms 8 Ft. 14,200-12,800 Lb. Capacity Blue | Uniform Upright Capacity 42"/48" Arm(lb.): 14,200 or 12,800 Component: Single-Sided Upright | 310 | ||
| XHDSA-C-36 |  | 1 Year Limited Warranty | Steel Extra Heavy Duty Cantilever Arm 36 In. Length 2,500 lb. Capacity Orange | Uniform Capacity Per Arm (lb.): 3,400 Component: Extra Heavy-Duty Arm | 30 | ||
| XHDSA-C-42 |  | 1 Year Limited Warranty | Steel Extra Heavy Duty Cantilever Arm 42 In. Length 2,500 lb. Capacity Orange | Uniform Capacity Per Arm (lb.): 2,900 Component: Extra Heavy-Duty Arm | 33 | ||
| XHDSA-C-48 |  | 1 Year Limited Warranty | Steel Extra Heavy Duty Cantilever Arm 48 In. Length 2,500 lb. Capacity Orange | Uniform Capacity Per Arm (lb.): 2,500 Component: Extra Heavy-Duty Arm | 36 |
