Japanese Engineered Spring Loaded Towing CastersThese Japanese engineered casters are one of the only in the market specially designed for spring-loading AND towing applications. Its high-performance polyurethane is abrasion resistant and tolerates longer distances, while providing great absorption. The state-of-theart caster raceway is made up of both a radial bearing that allows for smooth operation for towing applications, and a thrust bearing, which provides paramount absorption for heavy loads. The springs provide extra support for sensitive product. Yellow tread color. 92 +/-5 Shore A. Made in China.
- Radial Bearing Supports Horizontal Force (Towing)
- Spring Loaded Supports Shock Absorption
- Thrust Bearing Supports Vertical Force (Load Impact)
- Non-Marking
- Noise Reduction
- Abrasion Resistant Polyurethane
Extra Heavy Duty Kingpinless Casters
Dual Wheel Polyurethane (SI) - Highly Ergonomic Upgrade Casters
Stainless Steel Nylon Caster
All measurements are approximate. Slight variations, tolerances or changes may occur at any time. Weights shown are approximate shipping weights.
The Search Box below is for Casters within the Model Chart on this page. Not an entire site search.
| Model | Image | PDFs | Caster Size |
Type | Capacity (lbs.) |
Overall Height |
Top Plate Size |
Net Wt. (lbs) |
|---|---|---|---|---|---|---|---|---|
| CST-G80-6X2PU-R |  | NONE Limited Warranty | 6 x 1-3/4 | RIGID | 308 - 550 | 7.28 - 8.07 | 4-1/2 x 6-1/4 | 9 |
| CST-G80-6X2PU-S |  | NONE Limited Warranty | 6 x 1-3/4 | SWIVEL | 308 - 550 | 7.28 - 8.07 | 4-1/2 x 6-1/4 | 9 |
KEY: = Click For Expanded Model Details -- = Approval Drawing -- = Testing Certificate -- Warranty
Japanese Engineered Spring Loaded Towing Casters PDF's will open in a new window when clicked.
